Air Date:
Latest update:
When you download a 'live' ISO, dd it to a USB drive, you notice that
all your tweaks or installed packages vanish after a reboot. If you
think about how most such 'live' ISOs work, it becomes apparent
why:
$ parted -s Fedora-Xfce-Live-44-1.7.x86_64.iso print free | grep '^[PN ]'
Partition Table: gpt
Number Start End Size File system Name Flags
1 32.8kB 2897MB 2897MB ISO9660 hidden, msftdata
2 2897MB 2929MB 31.5MB fat16 Appended2 boot, esp
2929MB 2929MB 512B Free Space
ISO9660 is a read-only filesystem, & the fact it was written onto a
writable medium is irrelevant: its fs driver contains no
implementation for writing data blocks, & the Linux VFS layer immediately
returns EROFS (code 30, Read-only file system) when it sees that a
fs was mounted read-only.
A common workaround is to use OverlayFS; in the case of 'live' ISOs, to
do an overlay with a chunk of RAM.
Obviously, you can do an overlay with a filesystem that supports write
operations instead, like ext4, but inside the Live ISO there isn't
one, & hence there is nothing to do an overlay with.
While you can always create an ext4 partition manually, how do you tell
the 'live' OS to use it during boot? This distro corner has no
standardisation whatsoever, & everybody is doing it in their own
unique way. E.g., Debian & Ubuntu have diverged so much throughout the
years that even the kernel parameters for their 'persistence'
implementations differ. While it may seem logical to an impartial
spectator to keep at least the user-facing interface the same between the
distros, it's not how it is done in practice.
Ubuntu
- Kernel parameter: "persistent".
- An (empty) partition must have the label "casper-rw".
What is annoying is that it's surprisingly non-obvious to detect
whether such a trick worked: if your partition is /dev/sda4, &
Ubuntu does not show it as mounted, & /cow is roughly the size of
/dev/sda4:
$ df -h | grep cow
/cow 9.8G 161M 9.2G 2% /
then persistence is on. If, on the other hand, you see this:
$ df -h | grep casper
/dev/disk/by-label/casper-rw 9.8G 161M 9.2G 2% /var/log
you most likely mistyped the word persistent.
The next issue is how to save grub parameters in the .iso. As it's
absolutely useless to mount it to modify files, you can either extract
everything from the .iso, edit what you want in grub.cfg, & recreate
the image, or, alternatively, do a simple 12-byte to 12-byte swap:
$ export LANG=C
$ sed -i 's/quiet splash/persistent /' xubuntu-26.04-desktop-amd64.iso
It's amusingly hacky, but works. If your replacement string is not equal
in length to the pattern, you'll corrupt the ISO9660 filesystem, &
grub will refuse to boot the kernel.
(See a github sample for a script that does all this; it assumes a
Linux host & injects an ext4 partition into a copy of an .iso. You can
always resize the partition (& its filesystem) in real time using the
Disks utility that the .iso ships with.)
Debian
- Kernel parameter: "persistence".
- A partition must have:
- the label "persistence";
- a file named
persistence.conf in the root of the partition with
a line akin to "/ union".
Notice that it was "persistent" for Ubuntu, but it's
"persistence" for Debian. Why not.
The same mechanism of rude byte swapping in the .iso applies here
too:
$ export LANG=C
$ sed -i 's/splash quiet/persistence /' debian-live-13.5.0-amd64-xfce.iso
Detecting a successful overlay is easier:
$ mount | grep sda3
/dev/sda3 on /run/live/persistence/sda3 type ext4 (rw,noatime)
overlay on / type overlay (rw,noatime,lowerdir=/run/live/rootfs/filesystem.squashfs/,upperdir=/run/live/persistence/sda3/rw,workdir=/run/live/persistence/sda3/work,redirect_dir=on)
Fedora
- Kernel parameters: "
selinux=0 rd.live.overlay=LABEL=foo:/bar".
- A partition must have:
- a label "foo" (choose whatever you want, but it must correspond to
the value in the kernel parameter);
- a "bar" directory (again, see the kernel parameter);
- an "ovlwork" directory (this is a hardcoded name).
To check:
$ df -h | grep sdb1
/dev/sdb1 9.8G 134M 9.1G 2% /run/initramfs/overlayfs
$ mount | grep Live
LiveOS_rootfs on / type overlay (rw,relatime,lowerdir=/run/rootfsbase,upperdir=/run/overlayfs,workdir=/run/ovlwork)
$ file /run/overlayfs
/run/overlayfs: symbolic link to /run/initramfs/overlayfs/bar
In the case of Fedora, this is all mostly useless. Its 'linux' loader
command in grub.cfg menu entries contains no space to sacrifice for
a different 40-byte-long string. You, of course, can delete one menu
entry completely & substitute it with your own, but this would be
rather fragile: if, in the next version of Fedora, the size of
grub.cfg changes, your script will corrupt the underlying ISO9660
filesystem.
If the only reliable way here is to extract the rootfs from the .iso
to edit it, why bother with overlays then? This is what Fedora Live
mounts during boot:
$ isoinfo -i Fedora-Xfce-Live-44-1.7.x86_64.iso -Jf | grep -i liveos/
/LiveOS/squashfs.img
Despite its name, it's a 2.6GB EROFS image file (the name is a
pun on a generic EROFS error code).
The image contains everything, including the kernel & initramfs. We
can just create 2 image files:
- a FAT32 one to hold
EFI/BOOT/BOOTX64.EFI, alongside the kernel &
initramfs;
- an ext4 one with a label, say "Fedora-Live", into which we extract
the contents of
squashfs.img.
The ext4 partition can be of any length, & our 'live' Fedora image
will have space to hold user files without any shenanigans with
overlays.
After creating these 2 images, we combine them into 1 (with a GPT
layout), & dd it onto a USB drive.
grub.cfg can be as short as:
set timeout=3
menuentry "Fedora Live" {
linux /vmlinuz rd.live.image root=LABEL=Fedora-Live rw noresume
initrd /initramfs
}
rd.live.image parameter is required for systemd to start
livesys service, otherwise, no
liveuser will be created.
The mechanism works for any official Fedora
spin.
See another github sample for a script that does all this. For a
quick test in QEMU, you'll need to specify a UEFI bios:
$ sudo ./mflip 10G Fedora-Xfce-Live-44-1.7.x86_64.iso out.img
$ alias qemu3d='qemu-kvm -machine q35 \
-bios /usr/share/OVMF/OVMF_CODE.fd -m 4G \
-display gtk,gl=on -smp 2 \
-device virtio-vga-gl,hostmem=2G,blob=true,venus=true'
$ qemu3d out.img
Tags: ойті
Authors: ag
Air Date:
Latest update:
I noticed this recently, though it started happening about a year ago.
On some websites (archive.org's bookreader), a normal <img> tag
suddenly began to look like some insane MS Internet Explorer extension
from 1998:
<img src="blob:https://example.com/b501e863-fe43-4b63-ae5d-dac14cac097e">
The web page that contains it renders the image fine, but when a
fairly naïve user posts that link into a chat, it results in
nothing: the blob referenced by <img> exists only in the memory of a
specific browser instance, & the server will return 404 for
any https://example.com/UUID.
Why do they do this? Every n years some people get scared of
hotlinking (bastards keep stealing our traffic), AI luddites try to
ruin business of evil corporations, & fans of toy-level DRM amuse
themselves with a new scheme.
If you look at the fetch-requests of such a page, you'll see
resources that look like images but actually aren't:
$ url='https://ia800206.us.archive.org/🙈.jpg'
$ curl -sI "$url" | grep -e type -e length -e obfuscate
content-type: image/jpeg
content-length: 267470
x-obfuscate: 1|uoEV6/PZOWtGhOZdVM898w==
$ curl -s "$url" | head -c25 | file -
/dev/stdin: data
Such a .jpg is encrypted. Part of the key is in the X-Obfuscate
header, but neither a random AI scraper nor any social network knows
about this. The cipher is also not disclosed, & every website may use
any scheme it wants: following any recommendations would defeat the
entire purpose of obfuscation.
The image-rendering algorithm then becomes:
download the encrypted file;
decrypt it using the key from the corresponding header & push the
result into a blob;
create a link to the blob using URL.createObjectURL function;
inject into the DOM an img element whose src attribute is equal
to the newly created link.
We can increase entropy further by writing our own custom element:
<img-blob alt="a fluffy cat" src="cat.bin"></img-blob>
that will do all of the above on its own. (I terser'ed the source
code of the example for I absolutely don't want you to use it in
anything serious: the entire approach is extremely user-hostile &
anti-web.)
For efficiency, archive.org AES-CTR-encrypts only the first 1024 bytes
of the image. Browsers know about AES but strictly require a secure
context that can be annoying during testing; hence, for mickey mouse
DRM we can simply use XOR-encryption.
The X-Obfuscate header itself can be obfuscated even more, e.g.:
x-obfuscate: rlW2MKWmnJ9hVwbtZFjtVzgyrFV6VPVkZwZ0AFW9Pt==
looks like a base64 string, but:
$ echo rlW2MKWmnJ9hVwbtZFjtVzgyrFV6VPVkZwZ0AFW9Pt== | base64 -d | xxd
base64: invalid input
00000000: ae55 b630 a5a6 9c9f 6157 06ed 6458 ed57 .U.0....aW..dX.W
00000010: 3832 ac55 7a54 f564 6706 7400 55bd 3e 82.UzT.dg.t.U.>
I checked if DeepSeek could figure it out: it spent 9 minutes & left
2 villages in Zhejiang province without water, was several times
very close to the target, but ultimately failed.
The string had been post-processed with rot13:
$ alias rot13="tr 'A-Za-z' 'N-ZA-Mn-za-m'"
$ echo rlW2MKWmnJ9hVwbtZFjtVzgyrFV6VPVkZwZ0AFW9Pt== | rot13 | base64 -d
{"version": 1, "key": "12345"}
As homework, you can add an equivalent of loading="lazy" to the
custom element using the Intersection Observer API.
Tags: ойті
Authors: ag
Air Date:
Latest update:
Pandoc can prepare LaTeX math for MathJax via its eponymous
--mathjax option. It wraps formulas in <span class="math">
elements and injects a <script> tag that points to
cdn.jsdelivr.net, which means rendering won't work offline or in
case of the 3rd-party server failure. You can mitigate this by
providing your own copy of the MathJax library, but the mechanism
still fails when the target device doesn't support JavaScript (e.g.,
many epub readers).
At the same time, practically all browsers support MathML. Use it
(pandoc's --mathml option), if you care only about the information
superhighway: your formulas will look good on every modern device and
scale delightfully. Otherwise, SVGs are the only truly portable
option.
Now, how can we transform the html produced by
$ echo 'Ohm'\''s law: $I = \frac{V}{R}$.' |
pandoc -s -f markdown --mathjax
into a fully standalone document where the formula gets converted into
SVG nodes?
- Use an html parser like Nokogiri, and replace each
<span class="math"> node with an image. There are multiple ways to
convert a TeX-looking string to an SVG: using MathJax itself (which
provides a corresponding CLI example), or by doing it in a
'classical' fashion with pdflatex. (You can read more about this
method in A practical guide to EPUB, chapters 3.4 and 4.6.)
- Alternatively, load the page into a headless browser, inject
MathJax scripts, and serialise the modified DOM back to html.
I tried the 2nd approach in 2016 with the now-defunct phantomjs. It
worked, but debugging was far from enjoyable due to the strangest bugs
in phantomjs. I can still run the old code, but it depends on an
ancient version of the MathJax library that, for obvious reasons,
isn't easily upgradable within the phantomjs pre-es6 environment.
Nowadays, Puppeteer would certainly do, but for this kind of task
I prefer something more lightweight.
There's also jsdom. Back in 2016, I tried it as well, but it was much
slower than running phantomjs. Recently, I gave jsdom another try and
was pleasantly surprised. I'm not sure what exactly tipped the scales:
computers, v8, or jsdom itself, but it no longer feels slow in
combination with MathJax.
$ wc -l *js *conf.json
24 loader.js
105 mathjax-embed.js
12 mathjax.conf.json
141 total
Roughly 50% of the code is nodejs infrastructure junk (including CL
parsing), the rest is a MathJax config and jsdom interactions:
let dom = new JSDOM(html, {
url: `file://${base}/`,
runScripts: /* very */ 'dangerously',
resources: new MyResourceLoader(), // block ext. absolute urls
})
dom.window.my_exit = function() {
cleanup(dom.window.document) // remove mathjax <script> tags
console.log(dom.serialize())
}
dom.window.my_mathjax_conf = mathjax_conf // user-provided
let script = new Script(read(`${import.meta.dirname}/loader.js`))
let vmContext = dom.getInternalVMContext()
script.runInContext(vmContext)
The most annoying step here is setting url property that jsdom uses
to resolve paths to relative resources. my_exit() function is called
by MathJax when its job is supposedly finished. loader.js script is
executed in the context of the loaded html:
window.MathJax = {
output: { fontPath: '@mathjax/%%FONT%%-font' },
startup: {
ready() {
MathJax.startup.defaultReady()
MathJax.startup.promise.then(window.my_exit)
}
}
}
Object.assign(window.MathJax, window.my_mathjax_conf)
function main() {
var script = document.createElement('script')
script.src = 'mathjax/startup.js'
document.head.appendChild(script)
}
document.addEventListener('DOMContentLoaded', main)
The full source is on Github.
Intended use is as follows:
$ echo 'Ohm'\''s law: $I = \frac{V}{R}$.' |
pandoc -s -f markdown --mathjax |
mathjax-embed > 1.html
The resulting html doesn't use JavaScript and doesn't fetch any
external MathJax resources. mathjax-embed script itself always works
offline.
Tags: ойті
Authors: ag
Air Date:
Latest update:
At the time of writing, the most recent Adobe Reader 25.x.y.z 64-bit
installer for Windows 11 weights 687,230,424 bytes. After
installation, the program includes 'AI' (of course), an auto-updater,
sprinkled ads for Acrobat online services everywhere, and 2 GUIs:
'new' and 'old'.
For comparison, the size of SumatraPDF-3.5.2 installer is 8,246,744
bytes. It has no 'AI', no auto-updater (though it can check for new
versions, which I find unnecessary, for anyone sane would install it
via scoop anyway), and no ads for 'cloud storage'.
The following chart shows how the Adobe Reader installer has grown in
size over the years. When possible, 64-bit versions of installers were
used.
Next Day Update:
Best comment on Hacker News: "Looks like a chart crime scene."
Alright, here's your linear graph, along with the
source from which both graphs were generated. All
point labels are version numbers.
Tags: ойті
Authors: ag
